TR-751A



Type: Amateur VHF transceiver
Frequency range: 144-148 MHz
Mode: All-mode
RF Power output: Hi: 25 W
Lo: 5 W
Sensitivity: SSB/CW: Better thatn 0.13 uV (10 dB S+N/N)
FM: Better than 0.2 uV (12 dB SINAD)
Selectivity: SSB/CW: 2.2 KHz (-6 dB), 4.8 KHz (-60 dB)
FM: 12 KHz (-6 dB), 24 KHz (-60 dB)
Image rejection: Better than 60 dB
Voltage: 11-16 VDC
Current drain: RX: Max 1 A
TX: Max 6 A
Impedance: 50 ohms, SO-239
Dimensions (W*H*D): 180*60*195 mm
Weight: 2.1 Kg
Manufactured: 198x-19xx
Other: 10 memories
Related documents: User manual (12.5 Mb)
